PCIe x1 1G One-way Transmission Ethernet Network Adapter (Intel I210)
LREC6230PF-TXRX is a one-way fiber gigabit Ethernet PCI Express x1 desktop adapter developed independently by Linkreal Co., Ltd. based on Intel I210 solution. While developing and designing this optical network card, its performance has been optimized and improved so that system I/O is no longer the bottleneck of network application. This adapter card has integrated hardware acceleration function and can perform TCP/UDP/IP checksum offloading and TCP segmentation tasks. Host processing technology can offload accelerators, and host processing technology can offload accelerators to free up CPU resources to process other applications. At the same time, due to the adoption of one-way data transmission, data is safer.
LREC6230PF-TXRX is a single-port one-way transmission fiber adapter card with INTEL I210 controller, which has high performance, high stability, high quality and very good compatibility.
LREC6230PF-TXRX is divided into TX and RX for use, and is used in combination with unidirectional transmission and unidirectional reception.
Complete technical details for integration and deployment planning.
Controller | Intel I210 | |||
Baffle Height | Full height and half height | |||
Power Consumption | 2*1.0W | |||
System Support | Windows 7/8/8.1/10 | |||
Windows Server 2008 R2/2012 R2/2016 R2/2019 /2019 R2; | ||||
Linux Stable Kernel version 2.6.32/3.x/4.x or later; | ||||
Linux CentOS/RHEL 6.5 / 7.x or later; | ||||
Ubuntu 14.x/15.x/16.x or later; | ||||
VMware ESX/ESXi 4.x/5.x/6.x or later | ||||
Bus Type | Mini PCIe | |||
Data rate supported per port | 1000Mbps | |||
Connector | 1*1G TX SFP interface + 1*1G RX SFP interface | |||
Standards compliant | IEEE802.3z 1000BASE-X Gbit/s Ethernet IEEE 802.3x Full Duplex and flow control IEEE 802.3ad Link aggregation for parallel links IEEE 802.1Q VLAN IEEE 1588 IEEE 802.3az - Energy Efficient Ethernet (EEE) | |||
iSCSI | YES | |||
WoL | No | |||
Jumbo Frames | YES | |||
DPDK | Yes | |||
PXE | Yes | |||
FCoE | No | |||
