PCIe x1 Single-port 2.5G Copper Ethernet Network Adapter (RTL8125BG)
LRES2022PT is a PCIe x1 2.5G Ethernet network adapter independently developed by Linkreal Co., Ltd. based on the Realtek RTL8125BG solution. This adapter card has a universal and low-cost way to deploy 2.5GbE Ethernet network connections. It can provide the network with four speed links: 2.5 Gbps, 1G, 100Mbps, 10Mbps. This product is designed to be used without the need for a 10 Gigabit port but a Gigabit network port, which can solve the computer's link demand for network speed.
This network adapter card adds a 2.5GBASE-T technology Ethernet port to the computer through the PCIe x1 slot. Can be widely used in industrial control computers, embedded computers, single board computers, digital multimedia and other network equipment, can achieve Windows, Linux and other system support. Through the existing Gigabit Ethernet network, 2.5 Gigabits, which is up to 250% higher than the Gigabit network speed, is realized, and an efficient, energy-efficient and cost-effective multi-gigabit Ethernet solution is realized.
PCIe x1 Single-port 2.5G Copper Ethernet Network Adapter (Intel I225): LRES2031PT
Complete technical details for integration and deployment planning.
| Power Consumption | 1.0W |
|---|---|
| System Support | Windows 7/8/8.1/10 |
| Bus Type | PCIe x1 |
|---|---|
| Data rate supported per port | 10/100/1000/2500MbE |
| Connector | 1*2.5G RJ45 |
| Standards compliant | IEEE 802.3bz (2.5GBASE-T)IEEE 802.3ab 1000BASE-T Gigabit EthernetIEEE 802.3u 100BASE-TX Fast EthernetIEEE 802.3i 10BASE-TIEEE 802.3x Full Duplex and flow controlIEEE 802.3ad Link aggregation for parallel linksIEEE 802.1Q VLANIEEE 1588IEEE 802.3az - Energy Efficient Ethernet (EEE) |
| iSCSI | No |
| WoL | Yes |
| Jumbo Frames | YES |
| DPDK | Yes |
| PXE | Yes |
| FCoE | No |
