OCP3.0 Dual-port 25G SFP28 Ethernet Network Adapter (Intel XXV710)
LRES3017PF-OCP is an OCP3.0 SFF dual optical port 25G ethernet network adapter developed by Shenzhen Lianrui Electronics Co., Ltd. based on the intel XXV710 master control solution.
The dual ports of the adapter can simultaneously support the self-adaptation of 1/10/25G link rate to meet the flexible use in network environments with different rate requirements, and provide reliable performance in flexible LAN and SAN networks.
LRES3017PF-OCP is mainly designed for servers and high-end network communication equipment. It can bundle and converge multiple ports at the same time into groups to achieve fault tolerance and redundancy to ensure network performance and expand network bandwidth. It can implement real-time self-detection and realize faulty ports Communications are routed to other members of the same group to continue running for uninterrupted high-performance communications. This adapter is becoming an ideal solution for deploying multiple networks and deploying network applications and environments on high-performance servers.
Based on Intel Intel 25G Ethernet MAC+PHY (media access controller and physical interface transceiver) dual-port controller, it has excellent compatibility with various operating systems and meets customers' needs for using networks with multiple operating systems.
The OCP3.0 SFF structure design adopted by the LRES3017PF-OCP Ethernet network adapter can adapt to the needs of the new and old server markets for network traffic and data distribution, processing, virtualization and big data computing in the current and long-term future.
Complete technical details for integration and deployment planning.
| Bus Type | OCP3.0 SFF |
|---|---|
| Data rate per port | 1 /10 /25 Gbps |
| Connector | 2 * 25G SFP28 |
| Power Supply | OCP |
| Protocol Support | IEEE P802.3by 25 Gb/sIEEE 802.11ae 10GBase-XIEEE 802.3z 1000BASE-X IEEE 802.3x Full Duplex and flow controlIEEE 802.3az Energy Efficient Ethernet IEEE 802.3zIEEE 802.1Q VLANsIEEE 802.3xIEEE 1588 PTP v1 & v2 |
| PXE | Yes |
| DPDK | Yes |
| WoL | No |
| Jumbo Frames | Yes |
| VMDq、SR-IOV | Yes |
| iSCSI | Yes |
| UEFI | Yes |
| NCSI | Yes |
| SACN CHAIN | Yes |
| 1588 PTP | No |
| Jumbo DataFrame Max | 9.5KB |
| ESD_Contact discharge | ±8KV(Class C) |
| ESD_Air discharge | ±15KV(Class C) |
| Operating Temperature | 0℃ to 50℃ (-32 ℉ to 122 ℉) |
| Storage Temperature | -40 ℃ to 70 ℃ (-40 ℉ to 158 ℉) |
| Storage Humidity | Maximum: 90% non-condensing relative humidity at 35 ℃ |
| Certification | FCC, CE, RoHS |
| PCB Size(mm) | 76*115*1.6 |
| Package Size(mm) | 179*150*30 |
| Weight(g) | * |
| 1/10G | Connection Status |
| Transfer status | Orange Link + Green Blink |
| 25G | Connection Status |
| Transfer status | Green Link + Green Blink |
| P/N | Description |
| LRES3017PF-OCP | OCP3.0 Dual-port 25G SFP28 Ethernet Network Adapter (Intel XXV710) |
